OptiPlex 5000 Tower Technical Specifications |
PROCESSOR OPTIONS
|
Intel® Pentium® Gold G7400, 6MB cache, 2 cores, 4 threads, up to 3.70GHz, 46W 12th Generation Intel® Core™ i3-12100, 12MB cache, 4
cores, 8 threads, 3.30GHz to 4.30GHz, 60W 12th Generation Intel® Core™ i3-12300, 12MB cache, 4 cores, 8 threads, 3.50GHz to 4.40GHz, 60W 12th Generation Intel® Core™ i5-12400, 18MB cache, 6 cores, 12 threads, 2.50GHz to 4.40GHz, 65W 12th Generation Intel® Core™ i5-12500 vPro®, 18MB cache, 6 cores, 12 threads, 3.00GHz to 4.60GHz, 65W 12th Generation Intel® Core™ i5-12600 vPro®, 18MB cache, 6 cores, 12 threads, 3.30GHz to 4.80GHz, 65W 12th Generation Intel® Core™ i7-12700 vPro®, 25MB cache, 12 cores, 20 threads, 2.10GHz to 4.90GHz, 65W |
OPERATING SYSTEM
|
Windows 11 Home, 64-bit Windows 11 Pro, 64-bit Windows 11 Downgrade (Windows 10 image) Windows 11 Pro National Education, 64-bit
Windows 11 CMIT Government Edition, 64-bit (China only) Kylin Linux® Desktop version 10.1 (China only) Ubuntu® Linux® 20.04 LTS, 64-bit |
MEMORY OPTIONS
|
4GB, 1 x 4GB, DDR4, 3200MHz, single-channel 8GB, 1 x 8GB, DDR4, 3200MHz, single-channel 8GB, 2 x 4GB, DDR4, 3200MHz, dual-channel
16GB, 1 x 16GB, DDR4, 3200MHz, single-channel 16GB, 2 x 8GB, DDR4, 3200MHz, dual-channel 16GB, 4 x 4GB, DDR4, 3200MHz, dual-channel 32GB, 1 x 32GB, DDR4, 3200MHz, single-channel 32GB, 2 x 16GB, DDR4, 3200MHz, dual-channel 32GB, 4 x 8GB, DDR4, 3200MHz, dual-channel 64GB, 2 x 32GB, DDR4, 3200MHz, dual-channel 64GB, 4 x 16GB, DDR4, 3200MHz, dual-channel 128GB, 4 x 32GB, DDR4, 3200MHz, dual-channel |
PRIMARY HARD DISK DRIVES
|
2.5inch, 1TB, 5400RPM, SATA, HDD
2.5inch, 2TB, 5400RPM, SATA, HDD 2.5inch, 500GB, 7200RPM, SATA, HDD 2.5inch, 1TB, 7200RPM, SATA, HDD 2.5inch, 500GB, 7200RPM, SATA, HDD, Self-Encrypting, Opal 2.0, FIPS 3.5inch, 4TB, 5400RPM, SATA, HDD 3.5inch, 1TB, 7200RPM, SATA, HDD 3.5inch, 2TB, 7200RPM, SATA, HDD M.2 2230, 256GB, PCIe NVMe, Class 35 SSD M.2 2230, 512GB, PCIe NVMe, Class 35 SSD M.2 2230, 1TB, PCIe NVMe, Class 35 SSD M.2 2230, 256GB, PCIe NVMe, Class 35 SSD, self-encrypting drive M.2 2280, 512GB, PCIe NVMe, Class 40 SSD, self-encrypting drive M.2 2280, 1TB, PCIe NVMe, Class 40 SSD, self-encrypting drive M.2 2280, 512GB, PCIe NVMe, Class 40 SSD M.2 2280, 1TB, PCIe NVMe, Class 40 SSD M.2 2280, 2TB, PCIe NVMe, Class 40 SSD |
GRAPHICS
|
Intel® UHD Graphics 710 with 12th Generation Intel® Pentium® Gold G7400 processor Intel® UHD Graphics 730 with 12th Generation
Intel® Core™ i3-12100, i3-12300, and i5-12400 processors Intel® UHD Graphics 770 with 12th Generation Intel® Core™ i5-12500, i5-12600, and i7-12700 processors AMD Radeon™ RX640, 4GB GDDR5 AMD Radeon™ 550, 2GB GDDR5 AMD Radeon™ 540, 1GB GDDR5 |
PORTS
|
Front:
USB 3.2 Gen 2 Type-C® port USB 2.0 Type-A port with PowerShare USB 2.0 Type-A port USB 3.2 Gen 1 Type-A port Universal audio jack Rear: (4) USB 3.2 Gen 1 Type-A ports (2) USB 2.0 Type-A ports with Smart Power On RJ45 Ethernet port (2) DisplayPort 1.4a ports Optional video port (HDMI 2.0b/DisplayPort 1.4a/ VGA/USB 3.2 Gen 2 Type-C port with DisplayPort Alt Mode) Serial/PS2 port (optional) |
OPTICAL DRIVE
|
8x DVD-ROM (optional)8x DVD±RW (optional)
|
DIMENSIONS
|
Height: 324.30mm (12.77in.) Width: 154.00mm (6.06in.)
Depth: 292.20mm (11.50in.) Weight (min): 5.41kg (11.94lb) Weight (max):7.34kg (16.18lb) |
CAMERA
|
No camera
|
AUDIO & SPEAKERS
|
Realtek Audio Controller, ALC3246-CG Internal speakers (optional)
|
WIRELESS
|
Intel® AX211, 2x2 MIMO, 2400Mbps,
2.40GHz/5GHz/6GHz, Wi-Fi 6E (WiFi 802.11ax), BT® 5.2 Realtek® RTL8821CE, 1x1, 433Mbps, 2.40GHz/5GHz, Wi-Fi 5 (802.11ac), BT® 5.0 Realtek® RTL8822CE, 2x2 MIMO, 867Mbps, 2.40GHz/5GHz, Wi-Fi 5 (802.11ac), BT® 5.0 |
POWER OPTIONS
|
240W internal power supply unit (PSU), 85%
Efficient, 80 Plus Bronze 260W internal power supply unit (PSU), 85% Efficient, 80 Plus Bronze 400W internal power supply unit (PSU), 92% Efficient, 80 Plus Platinum |
CHIPSET
|
Intel® Q670
|
Warranty
|
3 Year
|
